加工性能及特點：

        專業(yè)用于加工uPVC及鋁合金門窗三孔執(zhí)手及五金件安裝槽。

        由水平方向的三孔鉆與垂直方向的仿型銑組成

        三孔鉆機頭上下運動增加了導柱導向，保證三個孔對底面的平行

        三孔鉆后置布置，操作方便，符合人體工學原理

        三孔鉆氣液阻尼自動進給，減輕了工人的勞動強度

        三孔鉆配有專用麻花鉆頭，可鉆削鋁合金及鑲有鋼襯板的uPVC型材。

        標準模板控制仿形尺寸，仿形比例1：1。

        雙階仿形針設計，適應多種仿形尺寸要求。

        可通過標尺控制，加工不同的槽。

技術參數：

        輸入電源 380V/50HZ                總功率 2.25KW

        工作氣壓 0.4-0.6MPa                耗氣量 30L/min

        主軸轉速 12000r/min                銑刀直徑 Φ5mm Φ8mm

        三孔鉆調整范圍 330*85*100mm  三孔鉆直徑 Φ10mm，Φ12 mm

       三孔鉆轉速  900r/min           仿形范圍290mm×90mm

       外形尺寸  4050×1130×1500mm    重 量  300kg

Processing Performance and Feature:

        Professional use for processing handles in three holes and the slots which for installing the hardwares.

        The three-hole driller has the special twist drill which can drill the aluminum alloy profile and PVC profile with steel inlaid.

        The copy routing size is controlled by the stardard template and the proportion is 1:1.

        Adopt the high-speed copy-routing milling head.

        Double-step copy routing design which suitable for the requirement in many kinds of size of copying.

        Can processing different slots controlled by the pole.

Technical Parameter
